SY-813
Exothermic Gas Generator
Application
- Continuous blackening tempering treating to metal parts(Treating temperature must be above 450℃)
Features
- Rich is deoxidation gas, weak decarbonization, little carbon lost, suitable for low/middle carbon's bright quenching, annealing, welding, etc.
- Lean is oxidation gas, strong decarbonization, no carbon lost, suitable for middle carbon's blackening treating and bright annealing for copper and alloy metal.
- Use the heating type gas generator gas blacking system, can not achieve the effect of salt spray test.
Specification
Model | Gas Producing Capacity (m3/hr) |
Power (kw) |
Outside Dimension (m/m) |
||
---|---|---|---|---|---|
Width | Height | Length | |||
SY-813-1 | 60 | 1.5 | 1850 | 2100 | 3400 |
SY-813-2 | 80 | 1.5 | 1850 | 2100 | 3700 |
SY-813-3 | 100 | 2.25 | 2050 | 2250 | 3300 |
SY-813-4 | 120 | 2.25 | 2050 | 2250 | 3600 |
SY-813-5 | 150 | 2.25 | 2050 | 2250 | 3900 |
Original Gas | Proportion of Gas & Air | Composition Range of Gas Generation | |||||
---|---|---|---|---|---|---|---|
CO | CO2 | H2 | CH4 | N2 | H2O | ||
CH4 | 1:6~9 | 8~1 | 7~10 | 15~10 | approx.0 | 68~86 | approx.2 |
C3H8 | 1:11~23 | 16~1 | 3~11 | 20~1 | 0 | 59~83 | 2 |
C4H10 | 1:13~30 | 18~1 | 2~3 | 22~1 | 0 | 56~83 | 2 |
CO2 | CO | H2 | CH4 | H2O | N2 | Dew point | |
---|---|---|---|---|---|---|---|
DX Lean | 10.5 | 1.5 | 0.8 | 0.0 | 0.8 | 86 | +5 |
DX Rich | 5.0 | 10.5 | 12.5 | 0.5 | 0.8 | 70.7 | +5 |
